Поршень Типа Scott U1383A-000

The Scott Brake Master Cylinder is one of the largest selling aircraft master cylinders in the world. Installed as standard equipment on Piper and other aircraft for many years, these units provide rugged and virtually trouble-free service with few wearing parts. One pair of master cylinders – one left hand (1248H) and one right hand (1260H) – is required on most aircraft. On the Piper Tri-Pacer, however, only one left master cylinder (1248H) is required. Specifications Maximum Working Pressure: 350 lbs Pedal Pressure: 100 lbs Recommended Hydraulic Fluid: MIL-H-5606 Weight as Shown: 21 ounces dry No. Description No. Description Master Cylinder, LH 7 Compression Cover Master Cylinder, RH 8 Piston 1 Vent Screw Gasket 9 Pedal, RH Unit 2 Bracket, RH Unit 10 Pedal, LH Unit 3 Bracket, LH Unit 11 Diaphragm 4 Diaphragm Pad 12 Screw MS35265-45 5 Spring 13 Nut 6 Vent Screw 14 Bolt AN3-20A
